Grade: TP304L
Standards: ASTM A269, ASTM A213
Sizes: 2mm ~ 76mm
Application: Annealed Stainless Tubing has no oxide layer, withstands high pressure and no leakage, high precision, high smoothness, no deformation of cold bending, flaring and flattening without crack, so Bright Annealed Tube is widely used for instrumentation, fluid equipment, automobile locomotives, locomotive brake system, gas equipment manufacturing and laboratory, etc.
Chemical Composition
|
Grade |
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
|
304L |
≦0.035 |
≦1.00 |
≦2.0 |
≦0.045 |
≦0.030 |
8.0~13.0 |
18.0~20.0 |
/ |
Feature:
|
Grade |
Mechanical Property |
Density |
Specific Resistance (10-8Ωm) |
Specific Heat 0 - 100℃ KJ/(kg．℃) |
Critical Temperature of Oxidation Resistance |
|||
|
Tensile Strength (N/mm2) |
Yield Strength (N/mm2) |
Elongation (%) |
Continuous use (℃) |
Intermittent Use (℃) |
||||
|
SS304L |
≥480 |
≥175 |
≥30 |
7.93 |
72 |
0.5 |
900 |
810 |
Size Chart (A):
|
O.D. |
W.T. (A) |
W.T. (B) |
|
|
In |
mm |
mm |
mm |
|
1/4 |
6.35 |
0.89 |
1.00 |
|
3/8 |
9.53 |
0.89 |
1.00 |
|
1/2 |
12.70 |
1.24 |
1.00 |
|
5/8 |
15.88 |
1.24 |
1.00 |
|
3/4 |
19.05 |
1.65 |
1.24 |
|
1 |
25.40 |
1.65 |
1.24 |
|
1-1/2 |
38.10 |
1.65 |
/ |
|
2 |
50.80 |
1.65 |
/ |
|
2-1/2 |
63.50 |
1.65 |
/ |
|
3 |
76.20 |
1.65 |
/ |
|
4 |
101.60 |
2.11 |
/ |
|
5 |
127.00 |
2.77 |
/ |
|
6 |
152.40 |
2.77 |
/ |
Size Chart (B):
|
O.D. |
W.T. |
||
| / |
mm |
Sch5S |
Sch10S |
|
6A |
10.50 |
1.00 |
1.20 |
|
8A |
13.80 |
1.20 |
1.65 |
|
10A |
17.30 |
1.20 |
1.65 |
|
15A |
21.70 |
1.65 |
2.10 |
|
20A |
27.20 |
1.65 |
2.10 |
|
25A |
34.00 |
1.65 |
2.80 |
|
32A |
42.70 |
1.65 |
2.80 |
|
40A |
48.60 |
1.65 |
2.80 |
|
50A |
60.50 |
1.65 |
2.80 |
|
65A |
76.30 |
2.10 |
3.00 |
|
80A |
89.10 |
2.10 |
3.00 |
|
90A |
101.60 |
2.10 |
3.00 |
|
100A |
114.30 |
2.10 |
3.00 |
|
125A |
139.80 |
2.80 |
3.40 |
|
150A |
165.20 |
2.80 |
3.40 |
TP304L Annealed Stainless Tubing: The Perfect Solution for High-Quality Piping Systems
Annealed Stainless Tubing is widely used in a variety of industries due to its excellent corrosion resistance, high strength, and clean appearance. TP304L Stainless Steel BA Tubing is a type of stainless steel tubing that is specifically designed for high-quality piping systems. In this blog post, we will discuss the benefits of using TP304L Stainless Steel BA Tubing and its applications in various industries.
What is TP304L Annealed Stainless Tubing?
TP304L Annealed Stainless Tubing is a type of stainless steel tubing that is manufactured using the cold rolled method. This method ensures a smooth, bright, and highly reflective surface finish known as Bright Annealed (BA). TP304L Stainless Steel BA Tubing is made from Type 304L stainless steel, which is an austenitic stainless steel alloy that offers excellent corrosion resistance and high-temperature strength.
Benefits of TP304L Annealed Stainless Tubing
1. Corrosion Resistance: TP304L Annealed Stainless Tubing offers excellent corrosion resistance, making it ideal for use in harsh environments and corrosive applications.
2. High-Temperature Strength: TP304L Annealed Stainless Tubing is able to withstand high temperatures of up to 870°C (1600°F) without any degradation in performance.
3. Aesthetics: TP304L Annealed Stainless Tubing offers a smooth, bright, and highly reflective surface finish that enhances the appearance of piping systems.
4. Cleanliness: TP304L Annealed Stainless Tubing has a smooth surface that is easy to clean and maintain, making it ideal for use in applications that require high levels of hygiene.
Applications of TP304L Annealed Stainless Tubing
1. Food and Beverage Industry: TP304L Annealed Stainless Tubing is commonly used in the food and beverage industry due to its excellent corrosion resistance and cleanliness. It is often used in the production of dairy products, beverages, and pharmaceuticals.
2. Chemical Industry: TP304L Annealed Stainless Tubing is widely used in the chemical industry for its excellent corrosion resistance and high-temperature strength. It is used in the production of chemicals, acids, and caustic solutions.
3. Oil and Gas Industry: TP304L Annealed Stainless Tubing is commonly used in the oil and gas industry for its high-temperature strength and corrosion resistance. It is used in the production of pipes, fittings, and valves.
Conclusion
TP304L Annealed Stainless Tubing is an excellent choice for high-quality piping systems in a variety of industries. The benefits of using this type of stainless steel tubing include excellent corrosion resistance, high-temperature strength, aesthetics, and cleanliness. Its applications in various industries include food and beverage, chemical, and oil and gas. With its superior properties, TP304L Annealed Stainless Tubing is the perfect solution for all your piping needs.
